Schneider SMD LED Indicator Light

The Schneider SMD Indicator Light is designed for clear visual status indication on electrical control panels, machinery and industrial equipment. Schneider Electric’s Harmony range includes a wide selection of pilot lights, indicator lights and other operator-interface components for industrial and building applications. Depending on the exact model, Schneider indicator lights are available with different operating voltages, colours, mounting arrangements and LED configurations.

For Pakistani electrical and automation applications, choosing the correct indicator light requires more than simply selecting a colour. The exact Schneider reference should be checked for its operating voltage, LED type, mounting diameter, colour, connection method and intended application. For example, Schneider’s XB7 range includes 22/25 mm LED pilot-light products, while other Harmony families use different designs and specifications. A current Pakistani supplier lists several Schneider XB7 LED pilot lights for 22/25 mm panel mounting.

Schneider’s Harmony products are designed for control and signalling applications where operators need a clear visual indication of equipment or circuit status. Depending on the model, an indicator can be used to show the presence of power, operating status, phase condition or another control-panel state. Schneider’s official catalogue includes pilot-light products with different LED colours and supply-voltage configurations. For example, the Harmony XB5 range includes pilot lights and voltage indicators with LED light sources and several colour options.

Before ordering a Schneider indicator light, check the exact part/reference number printed on the product or required by the panel design. This is particularly important when replacing an existing indicator because two products may look similar while having different operating voltages, terminal arrangements or mounting requirements.

HN Electric supplies electrical and industrial control products for customers in Pakistan. If you are checking the Schneider indicator light price in Pakistan, select the correct model and specification before ordering. For project quantities, it is also useful to confirm stock and availability before placing the order.

For installation or replacement work, the electrical supply should be isolated and the product installed according to Schneider’s instructions and the requirements of the control panel. The correct voltage must always be applied to the selected indicator.

FAQs

What is a Schneider indicator light?

A Schneider indicator light, also called a pilot light, is a panel-mounted visual signalling device used to show the status or condition of electrical equipment or a control circuit.

What voltage does a Schneider LED indicator light use?

It depends on the exact Schneider reference. Harmony products are available with different supply-voltage specifications, so the model number should be checked before connecting the device. Schneider’s XB5 range, for example, includes different voltage configurations.

What size panel hole is required?

The required mounting diameter depends on the product family. Schneider XB7 products listed in Pakistan include 22/25 mm LED pilot-light configurations.

Can I replace my existing indicator light with any Schneider model?

Not necessarily. Check the mounting size, voltage, colour, terminals and Schneider reference before replacing an existing indicator.
